Actuator - v0.6 release notes

The main takeaway from this update is the API. This new version is a first step towards v1.0. Now, most common operations can be reused via “actuator.api” import. On of the neat things about this release is a “state” object. With this object the user is now can store the state between sequence executions. One of the many applications is cycling through tools or brushes.

Fixes and changes

• Fix: Once created, script steps and Filter steps of the same type share the settings.
• Change: Simplified menu, Tools – Augmented Brush – Actuator – Configure is now Tools – Augmented Brush – Actuator: Configure

API

Note that the API is a subject to change in the future. Keep watch on console output for deprecation warnings.

For up to date API reference consult this page.

Keystrokes

Functions:

• send_keystroke – generate keystroke like “Ctrl+J” by providing the string with a keystroke. Only supported on Windows.

List of supported keys:

‘LMButton’, ‘RMButton’, ‘MMButton’, ‘Backspace’, ‘Tab’, ‘Enter’, ‘Shift’, ‘Ctrl’, ‘Alt’, ‘CapsLock’, ‘Esc’, ‘Space’, ‘PgUp’, ‘PgDn’, ‘End’, ‘Home’, ‘Left’, ‘Up’, ‘Right’, ‘Down’, ‘Ins’, ‘Del’, ‘0’, ‘1’, ‘2’, ‘3’, ‘4’, ‘5’, ‘6’, ‘7’, ‘8’, ‘9’, ‘A’, ‘B’, ‘C’, ‘D’, ‘E’, ‘F’, ‘G’, ‘H’, ‘I’, ‘J’, ‘K’, ‘L’, ‘M’, ‘N’, ‘O’, ‘P’, ‘Q’, ‘R’, ‘S’, ‘T’, ‘U’, ‘V’, ‘W’, ‘X’, ‘Y’, ‘Z’, ‘LWin’, ‘RWin’, ‘-‘, ‘.’, ‘/’, ‘F1’, ‘F2’, ‘F3’, ‘F4’, ‘F5’, ‘F6’, ‘F7’, ‘F8’, ‘F9’, ‘F10’, ‘F11’, ‘F12’, ‘F13’, ‘F14’, ‘F15’, ‘F16’, ‘F17’, ‘F18’, ‘F19’, ‘F20’, ‘F21’, ‘F22’, ‘F23’, ‘F24’

User Interface

Is a bulk part of the api. With these symbold use will be able to quickly construct interactive sequence without much of a coding.

Dialogs

Classes:

• CustomIntDialog – Create this dialog to extract the integer value from a user
• SelectItemsDialog – Dialog to let the user select multiple items with a checkbox

Functions:

• get_color_with_dialog – Show color-picker dialog to select color
• get_selected_items – Provide the function with a list of items and get list of selected indices

Actions

Scripting alternatives to built in actions.

Classes:

• Action – analog of Krita.instance().action(“”)

There are following actions implemented:

• deselect
• duplicate

Color

Functionality to manipulate colors

Functions:

• rgba_to_hexa – Convert RGBA (123, 245, 123, 210) to HEX with alpha (#945d5dff)
• rgba_to_hex – Convert RGBA (123, 245, 123, 210) to HEX without (#945d5d)
• hex_to_rgb – Convert HEX color #945d5d to RGB value (231, 12, 54)
• rgb_to_hsl – Convert RGB to HSL
• hex_to_hsl – Convert HEX color string to HSL
• rgb_to_hsv – Convert RGB to HSV
• hex_to_hsv – Convert HEX string to HSV

Utils

Functions:

• halt – wait for some time before continuing operations

Objects:

• state – Pure python dictionary. Useful to save state between sequence executions. Preserves the state only during application runtime. After closing the application the state is lost.
